Breckland Apex Studio

Apex style garden studio with UPVC doors & windows

Technical Information




Available Sizes

All sizes available - please ask for details

Standard Specification

  • Internal fitting of customer cables (first fix only)​

  • Cladding - Redwood Thermowood T&G 19mm x 125mm (16mm finish).

  • Solvent based treatment to cladding, roof and floors with moisture resistant membrane.

  • Floor - 18mm moisture resistant chipboard sheets and 3" x 2" pressure treated redwood floor joists.

  • Roof - 18mm Exterior grade OSB boards, 3" x 2" redwood framework and 38kg polyester based mineral flat.

  • Roof overhang - Standard Apex - 2" all round. Reverse Apex - 12" to front and 2" to side and back.

  • Doors & Windows - UPVC double glazed units

  • Door & Window style - Plain glazing - Up to and including 10' x 6' - single door with 2 small windows. Over 10' x 6' - single door and 3 small windows. Glass to ground glazing - Double doors, 2 fixed windows to the front and 1 top vented windows each side.

Optional Extras

  • Painted external finish

  • Painted internal V grooved MDF and insulation

  • Partition

  • Veranda

  • Reverse Apex

  • Larger overhang

  • Open sided area

  • Extra board height

  • Additional UPVC doors and windows

  • Aluminium doors and windows

  • Shed doors and windows

  • No floor

  • Non-standard shape

  • Bolt to existing building

  • Guttering and downpipes

  • Workbenches and shelves

  • Cedar shingle roof

  • Eco slate tile roof

  • EPDM rubber roof

  • Thermowood slatted roof

  • LED Light package
